Motion Slider

Before and After Image Reveal Example

This shows how this plugin can be easily customized to create a cool way to show a before and after image. In the examples below, it shows the original image and the final image after being edited to look like an old picture.
To use: Drag the handle to reveal the "after" image.

As an alternative to the first example, this example shows the step-by-step process instead of just showing the before and after image.
To use: Drag the scroller below or click/tap the text to jump to that step.
Original
Recolor
Add Image
Glow
Add Soft
Edges
Create
Grainy Look
Add
Scratches
Adjust
Levels
1
2
3
4
5
6
7
The HTML below is used to generate the slider above.
 HTML Simple Version
<div id="simpleRevealSlider" class="slider" data-elem="motionslider" data-options="animDuration:0.5">
   <div class="slidesHolder" data-elem="slidesHolder" >
      <div class="slide" data-elem="slide" data-options="neverPlay:true">
         <img alt="image" src="#" data-src="assets/step1.jpg" class="stepImg"/>
         <div class="imgMask" data-motion="{width:100%; duration:1; ease:Linear.easeNone}">
            <img alt="image" src="#" data-src="assets/step7.jpg" class="stepImg"/>
         </div>
      </div>
      <div data-elem="controls">
         <div class="revealSeek" data-elem="seek">
            <div class="revealThumb" data-elem="thumb">
               <div class="revealLine"></div>
               <div class="thumbHolder">
                  <div class="thumbImg"></div>
               </div>
            </div>
         </div>
      </div>
   </div>
</div>
 HTML Step Version
<div id="stepRevealSlider" class="slider" data-elem="motionslider" data-options="allowDrag:false">
   <div class="slidesHolder" data-elem="slidesHolder" >
      <div class="slide" data-elem="slide" data-options="neverPlay:true">
         <img alt="image" src="#" data-src="assets/step1.jpg" class="stepImg"/>
         <div class="blurMask">
            <img alt="image" src="#" data-src="assets/step1_part_blur.jpg" class="blurImg"/>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:0}">
            <img alt="image" src="#" data-src="assets/step2.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step2_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:1}">
            <img alt="image" src="#" data-src="assets/step3.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step3_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:2}">
            <img alt="image" src="#" data-src="assets/step4.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step4_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:3}">
            <img alt="image" src="#" data-src="assets/step5.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step5_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:4}">
            <img alt="image" src="#" data-src="assets/step6.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step6_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepHolder" data-motion="{type:from; autoAlpha:0; duration:1; ease:Linear.easeNone; delay:5}">
            <img alt="image" src="#" data-src="assets/step7.jpg" class="stepImg"/>
            <div class="blurMask">
               <img alt="image" src="#" data-src="assets/step7_part_blur.jpg" class="blurImg"/>
            </div>
         </div>
         <div class="stepBg" data-motion="{alpha:0.3; immediateRender:true}"></div>
         <div class="hidden-phone stepTextHolder">
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:0" data-motion="{autoAlpha:0.6; immediateRender:true}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Original<br>Image</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:1" style="left:104px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:0}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Recolor<br>Image</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:2" style="left:208px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:1}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Add Image<br>Glow</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:3" style="left:312px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:2}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Add Soft<br>Edges</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:4" style="left:416px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:3}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Create<br>Grainy Look</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:5" style="left:520px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:4}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">Add<br>Scratches</div>
            <div class="sliderText stepText" data-elem="slideThumb" data-options="time:6" style="left:624px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:5}">Adjust<br>Levels</div>
         </div>
         <div class="visible-phone stepTextHolder">
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:0" data-motion="{autoAlpha:0.6; immediateRender:true}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">1</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:1" style="left:104px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:0}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">2</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:2" style="left:208px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:1}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">3</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:3" style="left:312px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:2}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">4</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:4" style="left:416px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:3}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">5</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:5" style="left:520px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:4}, {autoAlpha:0.2; duration:1; ease:Linear.easeNone;}">6</div>
            <div class="sliderText stepNumber" data-elem="slideThumb" data-options="time:6" style="left:624px;" data-motion="{autoAlpha:0.2; immediateRender:true}, {autoAlpha:0.6; duration:1; ease:Linear.easeNone; delay:5}">7</div>
         </div>
         <div data-motion="{target:#cbg; autoAlpha:0.6; immediateRender:true}" ></div>
      </div>
      <div data-elem="controls">
         <div class="controlHolder">
            <div id="cbg"></div>
            <div class="seekControl" data-elem="seek">
               <div class="seekBg"></div>
               <div class="seekThumb" data-elem="thumb">
                  <div class="revealThumbBg"></div>
               </div>
            </div>
         </div>
      </div>
   </div>
</div>
 CSS
.slider, .slide, .slideHolder
{
   width:727px;
   height:490px;
   overflow:hidden;
}


.stepImg
{
   position:absolute;
   left:0px;
   top:0px;
   width:727px;
   height:490px;
}


.imgMask
{
   width:0%;
   height:100%;
   left:0px;
   top:0px;
   position:absolute;
   overflow:hidden
}


.blurMask
{
   width:727px;
   height:65px;
   position:absolute;
   left:0px;
   top:425px;
   overflow:hidden
}


.blurImg
{
   position:absolute;
   left:0px;
   bottom:0px;
   width:727px;
   height:490px;
}


.stepBg
{
   width:727px;
   height:65px;
   position:absolute;
   left:0px;
   top:425px;
   overflow:hidden;
   background-color:#000
}


.stepHolder
{
   position:absolute;
   left:0px;
   top:0px;
}


.stepTextHolder
{
   position:absolute;
   left:0px;
   top:425px;
}


.stepText
{
   width:104px;
   height:65px;
   background-color:#000;
   position:absolute;
   left:0px;
   color:#FFF;
   font-size:15px;
   padding-top:12px;
}


.stepNumber
{
   width:104px;
   height:65px;
   background-color:#000;
   position:absolute;
   left:0px;
   color:#FFF;
   font-size:25px;
   padding-top:12px
}


.revealSeek
{
   width:100%;
   height:100%;
   position:absolute;
   top:0px;
   left:0px;
   overflow:hidden;
   cursor:pointer
}


.revealThumb
{
   width:1px;
   height:100%;
   position:absolute;
   position:left:0px
}


.revealLine
{
   width:2px;
   height:100%;
   position:absolute;
   left:-1px;
   top:0px;
   background-color:#FFF
}


.thumbHolder
{
   width:1px;
   height:1px;
   position:absolute;
   top:50%
}


.thumbImg
{
   width:62px;
   height:32px;
   background:url(../assets/reveal_thumb.png) no-repeat;
   left:-31px;
   top:-16px;
   position:absolute
}


.controlHolder
{
   height:30px;
   bottom:-10px;
   position:absolute;
   background:none;
   overflow:hidden
}


.seekControl
{
   position:absolute;
   left:7.132682255845942%;
   right:7.032682255845942%;
   border-radius:0px;
   cursor:pointer;
}


.seekControl
{
   height:10px;
   position:absolute;
}


.seekBg
{
   width:100%;
   height:10px;
   left:0px; bottom:-10px;
   position:absolute;
   background-color:transparent
}


.seekThumb
{
   width:16.66639614855571%;
   height:20px;
   background:url(../assets/step_reveal_thumb.png) no-repeat center center;
   position:absolute;
   border:none;
   border-radius:0px;
   top:0px;
}


.revealThumbBg
{
   width:100%;
   height:10px;
   position:absolute;
   left:0px;
   top:10px;
   background-color:#999999
}


#cbg
{
   width:100%;
   height:10px;
   left:0px;
   bottom:10px;
   position:absolute;
   background-color:#999999
}


.sliderText
{
   cursor:pointer;
   -webkit-user-select: none;
   -moz-user-select: none;
   -ms-user-select: none;
   -o-user-select: none;
   user-select: none;
}
